Diagnostic Equipment CNC Machined Aluminum Frame Medical Imaging Housing Parts Assembly
Product Details:
| Place of Origin: | China, Fujian |
| Brand Name: | Customized |
| Certification: | ISO9001:2015 |
| Model Number: | Customized |
|
Detail Information |
|||
| Name: | Custom CNC Aluminum Diagnostic Equipment Frame Med | Cnc Machining Or Not: | CNC Machining |
|---|---|---|---|
| Micro Machining Or Not: | Not Micro Machining | Type: | Milling, Turning |
| Material Capabilities: | Aluminum, Copper, Stainless Steel, Brass | Material: | Aluminum 6061-T6, 5083 |
| Tolerance: | ±0.02mm | Surface Treatment: | Clear Anodized, Powder Coated, Chemical Film |
| Service: | Customized OEM | Color: | White, Silver, Medical Gray |
| Equipment: | CNC Machining Centers, 4-Axis, 5-Axis | Sample: | Available |
| Material: | Aluminum 6061-T6 | Surface Treatment: | Anodized |
| Tolerance: | +-0.01mm | Process: | CNC Milling, CNC Turning |
| Highlight: | Precision CNC Machined Aluminum,ISO9001:2015 Certified Manufacturing,Medical Device Biocompatible Parts |
||
Product Description
Diagnostic Equipment CNC Machined Aluminum Frame Medical Imaging Housing Parts Assembly
Product Overview
Custom CNC Aluminum Diagnostic Equipment Frame Medical Imaging Device Housing Parts - expertly manufactured by Xiamen Shangshang Technology, an ISO9001:2015 certified precision CNC machining factory with 18+ years of experience since 2007. This precision component is machined from high-grade aluminum alloy using advanced CNC equipment, ensuring exceptional dimensional accuracy, superior surface quality, and outstanding structural integrity for demanding applications.
Designed for CT Scanners, MRI Components, X-ray Equipment, Ultrasound Devices, this part delivers reliable performance in challenging environments. Our manufacturing process includes comprehensive quality inspection at every stage - from raw material verification through in-process checks to final CMM dimensional validation.
Technical Specifications
| Product Name | Custom CNC Aluminum Diagnostic Equipment Frame Medical Imaging Device Housing Parts |
| Material | Aluminum 6061-T6, 5083 |
| Application | CT Scanners, MRI Components, X-ray Equipment, Ultrasound Devices |
| Machining Tolerance | ±0.02mm |
| Surface Treatment | Clear Anodized, Powder Coated, Chemical Film |
| Color / Finish | White, Silver, Medical Gray |
| Dimensions | Per equipment specification |
| Manufacturing Process | CNC Milling, CNC Turning, Welding, Stress Relief, Assembly |
| Quality Standard | ISO9001:2015 |
| OEM/ODM | Available - Custom per drawing/sample |
| Inspection | 100% Inspection + CMM Report + Material Cert |
| Lead Time | Samples: 7-14 days | Production: 15-30 days |
Factory Strength & Manufacturing Excellence
Company Profile - Xiamen Shangshang Technology Co., Ltd.
| Established | 2007 - 18+ Years Precision Manufacturing Heritage |
| Facility Size | 3,000-5,000 m² Modern Manufacturing Space |
| Workforce | 50-150 Skilled Engineers & Technicians |
| Business Type | Manufacturer & Exporter (Factory Direct) |
| Export Ratio | 60%-70% - Products Shipped to 30+ Countries |
| Certification | ISO9001:2015 Certified Quality Management System |
| Core Competencies | CNC Turning, CNC Milling, Cold Heading, Stamping, Welding, Assembly |
Advanced Manufacturing Equipment
| Equipment Type | Specification & Capability | Quantity |
|---|---|---|
| CNC Machining Centers (4-Axis) | Max 800x500mm, spindle 12,000 RPM, ±0.005mm | 15+ |
| 5-Axis CNC Machining Centers | Single-setup complex geometry, ±0.005mm | 3+ |
| CNC Turning Centers | Max 300mm x 500mm, precision ±0.005mm | 20+ |
| CMM (Coordinate Measuring Machine) | 3D measurement, accuracy 0.001mm | 2 |
| Surface Grinding Machines | Flatness ≤ 0.005mm, surface finish Ra 0.4um | 5+ |
| Salt Spray Tester | ASTM B117 corrosion resistance validation | 1 |
| Rockwell Hardness Tester | Material hardness verification HRB/HRC | 2 |
| Roughness Tester | Surface roughness Ra 0.4-3.2um verification | 2 |
EEAT Trust Framework - Why Choose Shangshang?
Experience
- Since 2007 - 18+ years in precision CNC machining
- 10,000+ custom projects completed for global clients
- Covering automotive, aerospace, medical, electronics, industrial sectors
- Deep expertise in aluminum alloys: 6061, 6063, 7075, 2024, 5052, A380
Expertise
- Engineers with 15+ years avg. CNC programming experience
- 5-axis simultaneous machining for complex geometries
- DFM analysis and feedback provided within 24 hours
- Tight-tolerance machining down to ±0.005mm
Authoritativeness
- ISO9001:2015 Certified quality management system
- Full material mill certificates with every shipment
- Comprehensive inspection: CMM reports, hardness tests, salt spray
- Approved supplier for automotive & aerospace supply chains
Trustworthiness
- 100% inspection before shipment - zero-defect policy
- Real factory - video tour available on request
- 60%-70% repeat customer rate - proven reliability
- 98.5%+ on-time delivery rate - consistently verified
- Secure packaging with full shipping insurance options
Frequently Asked Questions
Q1: Are you a factory or trading company?
A: We are a real manufacturer with 3,000-5,000 m² facility in Fujian, China, 50-150 employees, and 50+ CNC machines. Factory video tours and on-site visits are always welcome.
Q2: What aluminum alloys do you machine?
A: 6061-T6, 6063-T5, 7075-T6, 2024-T3, 5052, 5083, A380 and more. Material certificates provided with every order.
Q3: What tolerances can you achieve?
A: Standard: ±0.01mm. Precision: ±0.005mm for critical features. CMM inspection reports verify all dimensions.
Q4: What is your MOQ?
A: 1 piece for prototypes. Tiered pricing for production - the larger your volume, the lower your unit cost.
Q5: How do I start an OEM project?
A: Send your 3D CAD (STEP/IGS/X_T) or 2D drawings (PDF/DWG). We provide DFM analysis and quotation within 24 hours. Samples produced for approval before mass production.
Q6: What surface treatments do you offer?
A: Clear/color anodizing, hard anodizing, chemical film (Alodine), passivation, powder coating, sandblasting, brushing, polishing, laser engraving, and more.
Q7: What is your typical lead time?
A: Samples: 7-14 working days. Mass production: 15-30 working days after sample approval. Rush orders available - contact our team.
Q8: How do you ensure quality?
A: ISO9001:2015 procedures: Incoming material inspection > First-article inspection > In-process QC > 100% final inspection. Full documentation package with every shipment.
Q9: What shipping methods and terms do you offer?
A: Sea freight (FCL/LCL), air freight, express (DHL/FedEx/UPS/TNT). FOB, CIF, EXW terms supported.
Q10: Can I get samples before bulk order?
A: Yes! Sample orders ship in 7-14 working days. Sample fees are refundable upon bulk order placement.
